Summary
AGRI hydraulic cylinder is a type of single piston rod and double acting hydraulic cylinder, They are used in many farmer machines, They are suitable for automatic furrow. farming and other farmland worlds. This series hydraulic cylinder has the characteristic of high frequency, high intensity and so on.
1. High intensity, high speed....intensity, fatigue design, adaptive hydraulic cylinder designed as per loading frequency analysis ere applied, and piston rod
selection, processing technology, welding technology are inspected through ultrasonic fault detection. As it is designed tar high pressure operation, it is featured in light weight, high intensity and high reliability.
2. many sizes, bore size tom 40mm to 250mm
3. Working pressure: 16~3 2 Mpa
4. Fixing type: trunnion or according to custom's requirements
5. Sealing system...seal rings of N0K from Japan and Parker from USA that can overcome engineering construction conditions. as well as special designed sealing system are applied to prevent grit and dust, reduce oil leakage.
6. Cylinder body.. the thickness of cylinder body and flange can be changed; the cylinder inner surfaces manufactured as per appropriate intensity and dimensions
have excellent roughness and rigidity and better wearing capacity after roll finishing.
7. Piston rod...high frequency quenching followed by hard chrome plating to improve rust proofing and wear and scar resisting performance.
8. Safety/buffer functions.. valves with slow stroke, counting balance end emergency close can be installed easily according to requirements. The concealed ones can
absorb the impact of buffer device at the end of stroke.
