QDX3 series worm gear operators
We can supply Valve operator - Worm & Bevel Gear Operators - QDX3 series worm gear operators.
Model |
Butterfly valve DN |
d |
b |
D |
D1 |
N-M |
A |
B |
C |
E |
H |
φ |
Output moment |
24:1 |
50-100 |
14-18 |
5 |
94 |
75 |
4-M8 |
201 |
148 |
175 |
45 |
75 |
150 |
270 |
|
125-150 |
20-22 |
5 |
115 |
89 |
4-M12 |
290 |
220 |
250 |
50 |
75 |
250 |
700 |
30:1 |
200-250 |
28-30 |
8 |
135 |
118 |
4-M12 |
315 |
238 |
300 |
63 |
85 |
300 |
700 |
|
250-300 |
32 |
10 |
135 |
118 |
4-M12 |
310 |
226 |
319 |
78 |
86 |
300 |
1200 |
60:1 |
350-400 |
32 |
10 |
185 |
160 |
4-M16 |
400 |
270 |
400 |
120 |
125 |
300 |
2000 |
