All critical electrical connections are encapsulated to resist penetration of moisture.
Specially designed to NEC and NEMA specs for rugged irrigation duty.
460/380 3 Phase, 60/50 HZ dual voltage, 1725 RPM (60 HZ), 1475 RPM (50 HZ).
Thermally protected; automatic reset.
Internal fin cooled.
Heavy duty bearings. |
|
Designed for soft starts.
High torque performance.
CSA approved.
Totally enclosed light weight easy to access top junction box.
Minimal AMP draw: full load current at rated voltage, 2.3 AMPS.
.625 shaft diameter with key and standard NEMA 56-C face bolt pattern.
Class F rated insulation.
One year limited warranty.
Each motor hi-pot tested. |
