KS(WPKS) |
|
SIZE | RATIO | A | AB | B | CC | E | F | H | HL | LL | Ms | N | G | Z | INPUT SHAFT | OUTPUT SHAFT | KG | HS | U | T×V | S | W×Y | 50 | 1/10 1/20 1/30 1/40 1/50 1/60 |
175 | 105 | 107 | 50 | 95 | 110 | 180 | 130 | 80 | 120 | 140 | 15 | 11 | 30 | 12 | 4×2.5 | 20 | 6×22.8 | 7 | 60 | 195 | 120 | 117 | 60 | 105 | 120 | 205 | 150 | 90 | 130 | 150 | 20 | 11 | 40 | 15 | 5×3 | 25 | 8×28.3 | 10.5 | 70 | 234 | 140 | 131 | 70 | 115 | 150 | 235 | 175 | 105 | 150 | 190 | 25 | 15 | 40 | 18 | 5×3 | 30 | 8×33.3 | 14.5 | 80 | 264 | 160 | 144 | 80 | 135 | 180 | 265 | 200 | 120 | 170 | 220 | 25 | 15 | 50 | 22 | 7×4 | 35 | 10×38.3 | 22 | 100 | 322 | 190 | 175 | 100 | 155 | 220 | 327 | 250 | 150 | 190 | 260 | 25 | 15 | 50 | 25 | 7×4 | 40 | 12×43.3 | 36 | 120 | 385 | 230 | 200 | 120 | 180 | 260 | 388 | 300 | 180 | 230 | 320 | 30 | 18 | 65 | 30 | 7×4 | 45 | 14×48.8 | 63 | 135 | 435 | 260 | 212 | 135 | 200 | 290 | 445 | 350 | 215 | 250 | 350 | 30 | 18 | 75 | 35 | 10×4.5 | 60 | 18×64.4 | 80 | 155 | 507 | 302 | 312 | 155 | 220 | 320 | 483 | 390 | 235 | 280 | 390 | 38 | 20 | 85 | 40 | 10×4.5 | 70 | 20×74.9 | 114 | 175 | 550 | 325 | 334 | 175 | 250 | 350 | 540 | 435 | 260 | 310 | 430 | 40 | 20 | 85 | 45 | 12×4.5 | 80 | 22×85.4 | 150 | 200 | 670 | 350 | 346 | 200 | 290 | 390 | 610 | 490 | 290 | 360 | 480 | 42 | 22 | 95 | 50 | 12×4.5 | 85 | 22×89.4 | 218 | |
